Airtac B52-MD Copper-Free Multi-Position Locking Cylinder B52-MD10X15S
AirTAC B52-MD Series Multi-Position Locking Cylinder (Copper-Free) - B52-MD10X15S
- Model: B52-MD10X15S
- Type: Multi-position lockable cylinder with copper-free construction
- Bore size: 10mm
- Stroke: 15mm
- Operation: Double-acting
- Working pressure: 0.05-0.9 MPa
- Locking positions: 3+1 (Front/Middle/Rear + Intermediate)
- Locking force: ≥35N (at 0.5MPa)
- Temperature range: -10℃ to 70℃
- Port size: M5×0.8
- Piston material: Copper-free aluminum alloy (A6063)
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 230g ±5g
- Dimensions: 100mm(L) × 34mm(W) × 34mm(H)
- ISO standard: 6432 (8mm mounting hole spacing)
- Protection rating: IP54
Specialized positioning cylinder featuring electromagnetic locking mechanism with copper-free construction for environments requiring metal contamination control. The three-stage magnetic locking provides precise intermediate stops with position repeatability ≤±0.2mm. Integrated shock absorbers reduce end-impact noise to ≤70dB(A).
- Semiconductor wafer handling robots
- Pharmaceutical production line positioning
- Multi-stage press tooling systems
- Food processing equipment (NSF compliant)
- Optical lens assembly automation
Installation requirements:
Requires 24VDC ±10% power for electromagnetic locks (0.5W consumption per lock).
Lubricate with ISO VG32 turbine oil before initial use. Avoid lateral loads exceeding 15N.
| Property | Property Value |
|---|---|
| sku | B52-MD10X15S |
