Airtac B52-MD Copper-Free Multi-Position Locking Cylinder B52-MD20X50S
AirTAC B52-MD Series Multi-Position Locking Cylinder (Copper-Free) - B52-MD20X50S
- Model: B52-MD20X50S
- Type: Multi-position locking cylinder with mechanical brake
- Bore size: 20mm
- Stroke: 50mm
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -10℃ to 70℃
- Material: Aluminum alloy body (copper-free treatment)
- Seal material: NBR/PU composite seals
- Port size: Rc1/8 (G1/8 optional)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Side-mount with multiple bracket options
- Locking positions: 3 fixed positions (standard)
- Repeat positioning accuracy: ±0.5mm
- Weight: 0.82kg
- Dimensions: 130mm(L) × 50mm(W) × 50mm(H)
Heavy-duty multi-station cylinder featuring a unique mechanical locking mechanism for precise intermediate positioning. The copper-free design prevents contamination in sensitive environments, while the double-acting operation ensures stable bidirectional force output. Integrated shock absorption reduces end-impact noise by 30% compared to standard cylinders.
- Precision fixture positioning in CNC machining centers
- Multi-stage press mechanisms for electronic component assembly
- Position-lock applications in semiconductor handling equipment
- Modular tooling systems requiring intermediate stops
- Automated packaging line indexing stations
Installation note:
Requires minimum 0.3MPa initial pressure for brake release.
Lubricate sliding surfaces with ISO VG32 hydraulic oil during maintenance.
Maximum lateral load capacity: 15N at mid-stroke position.
| Property | Property Value |
|---|---|
| sku | B52-MD20X50S |
