Airtac B52-MF Copper-Free Stainless Steel Mini Cylinder B52-MF40X60U
AirTAC B52-MF40X60U Copper-Free Stainless Steel Mini Cylinder Specifications
- Model: B52-MF40X60U
- Bore size: 40mm
- Stroke: 60mm
- Material: SUS304 stainless steel (copper-free design)
- Rod end thread: M10×1.25
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable buffer (both ends)
- Mounting style: Basic type (MF series standard)
- Port size: M5×0.8 (dual ports)
- Piston speed: 50-750 mm/s
- Lubrication: Non-lubricated (pre-lubed for maintenance-free operation)
- Weight: 0.85 kg
- Dimensions: 150mm(L) × 40mm(W) × 40mm(H)
- Protection rating: IP67 (wipers included)
- Piston rod material: SUS420 stainless steel
Ultra-compact corrosion-resistant cylinder with medical-grade surface finish (Ra≤0.8μm). Features dual anti-rotation guide rods for precise linear motion and magnetic piston for position sensing compatibility. Copper-free construction meets semiconductor and food processing requirements.
- Cleanroom automation in semiconductor manufacturing
- Precision dispensing systems for medical devices
- Compact packaging machinery with space constraints
- Pharmaceutical tablet pressing equipment
- Laboratory sample handling robots
Installation note:
Use stainless steel fasteners only. Maintain 0.5mm alignment tolerance during mounting.
For vertical installations, add external guide mechanism if lateral force exceeds 5N.
Perform 50 low-pressure break-in cycles before full operation.
