Airtac B52-PB Copper-Free Pen-Type Cylinder B52-PB12X25SU
AirTAC B52-PB12X25SU Copper-Free Miniature Cylinder Specifications
- Model: B52-PB12X25SU
- Type: Single-acting spring return (push type)
- Bore size: Φ12mm
- Stroke: 25mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Ambient humidity: ≤95% RH (non-condensing)
- Piston speed: 50–800 mm/s (optimal at 200–400 mm/s)
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 pneumatic thread
- Mounting style: Front flange with male thread (M12x1.25)
- Material: Aluminum alloy body (copper-free), NBR seals
- Surface treatment: Hard anodized piston rod
- Weight: 0.23kg (without accessories)
- Dimensions: 70mm(L) × Φ20mm(W) × Φ12mm(H) (body only)
- ISO standard: Compliant with ISO 6432 miniature cylinder specs
Ultra-compact pneumatic cylinder specifically engineered for copper-sensitive environments, featuring corrosion-resistant construction and precision linear motion. The copper-free design prevents chemical reactions in medical/pharmaceutical applications. Integrated cushioning mechanism allows smooth end-of-stroke deceleration.
- Laboratory analyzer sample handling systems
- Semiconductor wafer processing equipment
- Medical device actuation mechanisms
- Precision dispensing valves in food packaging
- Optical lens positioning systems
Installation guidelines:
Use copper-free air lines (prefer nylon/PU tubing). Lubricate with ISO VG32 or equivalent non-acidic oil.
Max side load: 3N. For vertical mounting, reduce payload by 30%. Requires 0.01μm filtration.
| Property | Property Value |
|---|---|
| sku | B52-PB12X25SU |
