Airtac B52-PB Copper-Free Pen-Type Cylinder B52-PB16X50SRLB
AirTAC B52-PB16X50SRLB Copper-Free Compact Cylinder Specifications
- Model: B52-PB16X50SRLB
- Type: Copper-free pen-type cylinder (double-acting)
- Bore size: 16mm
- Stroke: 50mm
- Operating pressure: 0.15–0.8 MPa
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Buffer type: Rubber cushion (adjustable)
- Mounting style: LB series - side fixed with through hole
- Rod end type: Female thread (M6×1.0)
- Seal material: NBR (nitrile rubber)
- Body material: Aluminum alloy (copper-free design)
- Weight: Approximately 0.45kg
- Dimensions: 104mm(L) × 30mm(W) × 25mm(H) (retracted state)
Ultra-compact pneumatic cylinder specifically engineered for environments requiring copper-free components. Features precision-ground rod and ISO 6432 compliant mounting dimensions. The copper-free construction prevents contamination in sensitive applications while maintaining corrosion resistance.
- Semiconductor manufacturing equipment
- Medical device actuation systems
- Cleanroom automation mechanisms
- Food processing machinery
- Precision clamping devices in electronics assembly
Installation notes:
Lubricate with phosphate-ester resistant grease (Molykote PG-641 recommended).
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use locking nut (AN5-04L) to prevent rotation.
Critical:
Strictly avoid copper-containing lubricants. Maximum side load capacity: 5N.
Requires 40μm filtered air with dew point -25℃ below ambient temperature.
| Property | Property Value |
|---|---|
| sku | B52-PB16X50SRLB |
