Airtac B52-RMS Non-Copper Magnetic Coupling Rodless Cylinder B52-RMS25X450LB
AirTAC B52-RMS25X450LB Copper-Free Magnetic Coupling Rodless Cylinder Specifications
- Model: B52-RMS25X450LB
- Type: Non-rotating rodless cylinder with magnetic coupling
- Bore size: Ø25mm
- Stroke: 450mm (17.72")
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -10℃ to 60℃ (non-freezing)
- Cushioning: Adjustable rubber buffers (both ends)
- Seal material: NBR + Special copper-free alloy components
- Port size: Rc1/8 (ISO G1/8 optional)
- Coupling type: Non-contact magnetic transmission (IP67 rated)
- Repeat positioning accuracy: ±0.5mm
- Max speed: 500-2000mm/s (pressure-dependent)
- Lateral load capacity: 30N at mid-stroke
- Weight: 2.65kg (with mounting brackets)
- Dimensions: 580mm(L) × 48mm(W) × 40mm(H)
- Protection rating: IP54 (standard), IP67 available as option
- Lubrication: Pre-lubricated (maintenance-free for 5000km travel)
Copper-free magnetic rodless cylinder designed for clean environments requiring strict metal contamination control. Features zero external leakage with patented magnetic coupling technology and hardened stainless steel guide rails. The LB variant includes dual-position magnetic sensors and enhanced side load capacity.
- Semiconductor wafer handling robots
- Pharmaceutical cleanroom automation
- Lithium battery production lines
- Food packaging machinery (NSF-compliant version)
- Precision optical equipment positioning
Installation notes:
Requires parallel alignment within 0.2mm/m. Use M6x1.0 mounting screws torqued to 3.5N·m.
Magnetic sensors must maintain 1.5-2.0mm gap from actuator. Avoid direct coolant exposure.
| Property | Property Value |
|---|---|
| sku | B52-RMS25X450LB |
