Airtac B52-RMT Copper-Free Magnetic Coupling Rodless Cylinder B52-RMT20X100SA
AirTAC B52-RMT20X100SA Copper-Free Magnetic Coupling Rodless Cylinder Specifications
- Model Decoding: B52(Series)-RMT(Rodless Magnetic Type)20(Bore 20mm)X100(Stroke 100mm)SA(Seal Type)
- Bore Size: 20mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating Pressure: 0.05-0.9 MPa
- Ambient Temperature: -10℃ to 70℃ (no freeze)
- Piston Speed: 50-800 mm/s (lubricated)
- Magnetic Force: ≥38N (at 0.5MPa)
- Repeat Positioning Accuracy: ±0.2mm
- Material: Aluminum alloy body with CR/NBR seals
- Weight: 1.45kg (bare cylinder), 1.68kg (with mounting brackets)
- Dimensions: 270mm(L) × 34mm(W) × 34mm(H) (retracted)
- Mounting: ISO 15552 standard profile
- Port Size: M5x0.8 (Rc1/8 adaptor included)
- Protection Class: IP54 (standard), IP67 optional
- Copper-Free Certification: Compliant with FDA 21 CFR 175.300
This copper-free magnetic rodless cylinder features non-sparking aluminum construction ideal for explosive atmospheres and cleanroom environments. The dual-channel magnetic coupling ensures zero leakage with position feedback capability. Special anodized surface treatment resists chemical corrosion from coolants.
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Lithium battery production lines (spark-free requirement)
- MRI-compatible medical equipment
- Food-grade automation with washdown requirements
Installation tip:
Maintain 0.5mm minimum clearance between magnetic slider and ferrous materials.
Use brass-free lubricant (ISO VG32 grade recommended) during maintenance.
