Airtac B52-RMT Copper-Free Magnetic Coupling Rodless Cylinder B52-RMT20X150SA
AirTAC B52-RMT20X150SA Copper-Free Magnetic Coupling Rodless Cylinder Specifications
- Model: B52-RMT20X150SA
- Type: Guided rodless cylinder with magnetic coupling
- Bore size: 20mm
- Stroke length: 150mm (±0.5mm tolerance)
- Operating pressure: 0.05-0.9 MPa
- Piston speed: 50-700 mm/s (cushioned)
- Copper-free construction: Aluminum alloy body with stainless steel components
- Magnetic coupling force: ≥35N
- Seal material: NBR + PU hybrid seals
- Temperature range: -10℃ to 80℃
- Mounting type: Dual linear guide rail integrated
- Weight: 1.8kg (excluding accessories)
- Dimensions: 190mm(L) × 34mm(W) × 34mm(H)
- Repeat positioning accuracy: ±0.1mm
- Protection rating: IP54 (standard), IP67 optional
Non-lubricated magnetic drive cylinder featuring copper-free design for semiconductor/medical applications. The dual-guide rail structure ensures high lateral load capacity (max 15N·m moment resistance). Integrated shock absorbers minimize end-of-stroke vibration. Optional Hall sensor slots for position feedback.
- Cleanroom automation systems (ISO Class 5+)
- Precision wafer handling robots
- Pharmaceutical blister packaging lines
- Electronics PCB assembly stations
- MRI-compatible medical equipment
Installation note:
Requires non-magnetic mounting surface (aluminum/stainless steel recommended).
Maintain 0.5mm minimum clearance between magnetic slider and ferrous objects.
Lubrication interval: 500km travel distance or 6 months (whichever comes first).
