Airtac B52-RMT Copper-Free Magnetic Coupling Rodless Cylinder B52-RMT32X100S
AirTAC B52-RMT32X100S Non-Copper Magnetic Coupling Rodless Cylinder Specifications
- Model: B52-RMT32X100S
- Type: Non-copper magnetic coupling rodless cylinder (copper-free design)
- Bore size: 32mm
- Stroke: 100mm
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Buffer type: Built-in air cushion (adjustable)
- Magnetic coupling force: ≥80N
- Mounting style: Side-mounted with multiple bracket options (M6 threaded holes)
- Seal material: NBR with copper-free components
- Port size: 1/4" NPT (G1/8 optional)
- Piston speed: 50–1000 mm/s
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Weight: 1.8kg (excluding accessories)
- Dimensions: 360mm(L) × 32mm(W) × 60mm(H) (stroke-dependent length)
Copper-free rodless cylinder with advanced magnetic coupling technology, designed for cleanroom environments and applications requiring strict metal contamination control. Features low-friction stainless steel guide rails and corrosion-resistant aluminum alloy body. Integrated shock absorption ensures smooth operation at high speeds up to 1m/s.
- Food processing/packaging machinery (copper-sensitive environments)
- Pharmaceutical production line automation
- Electronics assembly with magnetic position sensing
- Cleanroom material handling systems
- Semiconductor manufacturing equipment
Installation notes:
Maintain parallel alignment during mounting (max 0.2mm/m deviation). Use regulated compressed air (40μm filtration) and avoid side-load forces. For optimal magnetic sensor performance, maintain 1-2mm gap between cylinder and detectors.
Copper-free compliance:
Contains no copper components in wetted parts (seals/pistons) – compatible with FDA and EU1935/2004 standards for food contact applications.
| Property | Property Value |
|---|---|
| sku | B52-RMT32X100S |
