Airtac B52-SDA Non-Copper Ultra-Thin Cylinder B52-SDA20X20SB
AirTAC B52-SDA20X20SB Copper-Free Ultra-Slim Cylinder Specifications
- Model: B52-SDA20X20SB
- Type: Double-acting ultra-slim cylinder (copper-free design)
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable rubber buffer
- Body material: Aluminum alloy (anodized copper-free treatment)
- Rod material: Stainless steel SUS304
- Seal material: NBR + PU hybrid seals
- Weight: 0.32kg ±2%
- Dimensions: 88mm(L) × 20mm(W) × 20mm(H) (retracted state)
- Protection rating: IP54 (standard), IP67 optional
- Built-in magnet: Yes (for magnetic sensor attachment)
Industry's thinnest 20mm-class pneumatic cylinder featuring copper-free construction to prevent contamination in sensitive environments. Precision honed tube ensures ≤0.01mm roundness tolerance. Optional auto switch grooves (M5 thread) on four sides for flexible sensor mounting. Low friction design achieves ≤0.15N starting pressure.
- Semiconductor wafer handling robots
- Medical device assembly lines
- High-cycle PCB component insertion
- Cleanroom automation systems
- Packaging machinery with space constraints
- Food processing equipment (copper-free compliant)
Installation note:
Lubricate with ISO VG32 or equivalent non-copper-based oils.
Maintain minimum 0.5mm clearance between rod end and load during alignment.
For vertical mounting, use counterbalance valves (sold separately).
