Airtac B52-SDA Non-Copper Ultra-Thin Cylinder B52-SDA25X120B
AirTAC B52-SDA25X120B Copper-Free Ultra-Thin Cylinder Specifications
- Model: B52-SDA25X120B
- Series: B52-SDA (Copper-Free Design)
- Bore size: 25mm
- Stroke: 120mm
- Operating pressure: 0.15–0.8 MPa
- Cushion type: Adjustable rubber buffer
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile Butadiene Rubber)
- Mounting style: Front/rear flange (ISO 15552 standard)
- Port size: 1/4" NPT
- Piston rod material: Stainless steel with hard chrome plating
- Protection rating: IP65
- Weight: 0.85kg ±3%
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H)
- Max theoretical thrust: 127N @0.6MPa
- Lubrication: Pre-lubricated (non-copper grease)
Ultra-slim cylinder (23% thinner than standard models) with full-copper-free construction for environments requiring metal contamination control. Features precision-machined aluminum alloy body with dual piston seals and wear-resistant guide rings. Requires filtered air (5-40μm) with ≤1mg/m³ oil content.
- Food processing equipment (copper-sensitive zones)
- Pharmaceutical production lines
- Semiconductor wafer handling systems
- High-speed sorting mechanisms (≤2m/s recommended)
- Medical device assembly automation
Installation guidance:
Maintain 0.5-1mm alignment tolerance during mounting. Use only zinc-nickel plated
or stainless steel fittings. Lubricate every 3,000km stroke distance with NSF-H1
certified grease if required.
| Property | Property Value |
|---|---|
| sku | B52-SDA25X120B |
