Airtac B52-SDA Non-Copper Ultra-Thin Cylinder B52-SDA25X35S
AirTAC B52-SDA Series Copper-Free Ultra-Thin Cylinder (B52-SDA25X35S)
- Model: B52-SDA25X35S
- Series: SDA (Copper-Free Design)
- Bore size: 25mm
- Stroke: 35mm
- Mounting type: Side mounting base (ISO 15552 standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Cushion type: Adjustable air cushion
- Port size: M5x0.8 (standard), optional NPT1/8
- Seal material: Nitrile rubber (NBR) with copper-free components
- Protection rating: IP40 (dust protected)
- Weight: Approximately 0.65kg (1.43 lbs)
- Dimensions: 135mm(L) × 54mm(W) × 25mm(H) (5.31"×2.13"×0.98")
- Rod thread: M6x1.0
- Max speed: 500mm/s (with cushion)
- Lubrication: Pre-lubricated (maintenance-free)
Ultra-slim profile cylinder (18% thinner than standard models) specifically engineered for copper-sensitive environments. Features aluminum alloy construction with anti-corrosion treatment, making it ideal for cleanrooms, medical equipment, and food processing applications. The integrated copper-free design prevents metallic contamination in regulated industries.
- Semiconductor manufacturing equipment
- Laboratory automation positioning systems
- Cleanroom conveyor systems
- Medical device actuation mechanisms
- Pharmaceutical packaging machines
- Precision optical component handling
Installation guidelines:
Requires minimum 5μm filtration for compressed air. Avoid side load forces exceeding 3N·m.
For vertical mounting, use locking nuts on piston rod threads. Lubricate guide shafts with
ISO VG32 hydraulic oil if used in high-cycle applications (>1 million cycles).
| Property | Property Value |
|---|---|
| sku | B52-SDA25X35S |
