Airtac B52-SDA Non-Copper Ultra-Thin Cylinder B52-SDA40X120S
AirTAC B52-SDA40X120S Copper-Free Ultra-Thin Cylinder Specifications
- Model: B52-SDA40X120S
- Type: Single-acting spring return (non-rotating)
- Bore size: 40mm
- Stroke: 120mm
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -10℃ to 70℃
- Cushion type: Adjustable rubber buffer
- Mounting style: Foot/Flange (optional accessories)
- Port size: M5x0.8 (standard), G1/8 available
- Material: Aluminum alloy body, copper-free components
- Special feature: ISO 13738 compliant copper-free design
- Seal material: NBR + PU combination
- Piston speed: 50–800 mm/s
- Protection rating: IP54 (standard), IP67 optional
- Weight: 0.82 kg ±3%
- Dimensions: 200mm(L) × 82mm(W) × 82mm(H) (including mounts)
Ultra-slim profile cylinder (16% thinner than standard models) engineered for corrosive environments requiring copper restriction. Features dual-layer seals for dry air compatibility and anodized surfaces. Includes anti-rotation guide slots (3mm depth) for precise linear motion. Requires Class 3 or cleaner compressed air.
- Semiconductor wafer handling robots
- Food-grade packaging machinery
- Copper-sensitive chemical processing equipment
- High-density automated test systems
- Medical device assembly lines
Installation note:
Lubricate with ISO VG32 or equivalent mineral oil before initial use.
Maintain minimum 5mm clearance from adjacent components for heat dissipation.
Horizontal mounting recommended for optimal seal life.
| Property | Property Value |
|---|---|
| sku | B52-SDA40X120S |
