Airtac B52-TCL Copper-Free Triple Rod Cylinder B52-TCL32X25S
AirTAC B52-TCL32X25S Copper-Free Triaxial Cylinder Specifications
- Model: B52-TCL32X25S
- Type: ISO standard triaxial cylinder with copper-free construction
- Bore size: Ø32mm
- Stroke: 25mm
- Operating pressure: 0.15–0.8 MPa
- Piston rod material: Hard chrome-plated stainless steel (SUS304)
- Cylinder tube: Aluminum alloy with copper-free anodizing
- Seal material: NBR + PU hybrid seals
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushioning (dual-side)
- Mounting options: Front flange (MF1), rear flange (MF2), foot mounting (MA3)
- Weight: 1.85kg ±2%
- Dimensions: 200mm(L) × 62mm(W) × 62mm(H)
- Protection rating: IP40 (standard), IP67 available on request
- Lubrication: Pre-lubricated (DOP-free grease)
High-precision triaxial cylinder featuring copper-free construction for environments prohibiting copper contamination. The X-shaped guide rail structure ensures ±0.05mm repeat positioning accuracy. Integrated shock absorption grooves reduce lateral vibration during multi-axis operation. Compatible with ISO 15552 mounting accessories.
- Pharmaceutical production lines (copper-sensitive processes)
- Semiconductor wafer handling robots
- Multi-axis dispensing systems for precision adhesives
- Food packaging machinery with HACCP requirements
- Cleanroom automation (Class 1000 or better)
Installation protocol:
Requires alignment within 0.2mm/m perpendicularity tolerance. Use M6×1.0 mounting screws
with 12.9-grade hardness. Maintain 1.5mm minimum clearance between guide rails and adjacent components.
| Property | Property Value |
|---|---|
| sku | B52-TCL32X25S |
