Airtac B52-TCL Copper-Free Triple Rod Cylinder B52-TCL50X60S
AirTAC B52-TCL50X60S Copper-Free Triple-Axis Cylinder Specifications
- Model: B52-TCL50X60S
- Type: Triple-axis guided cylinder (copper-free construction)
- Bore size: Ø50mm
- Stroke: 60mm
- Operating pressure: 0.1–0.9 MPa
- Material: Aluminum alloy body, CR12MoV piston rod
- Seal material: NBR/FKM (optional)
- Cushioning: Adjustable hydraulic buffer
- Temperature range: -20℃ to 80℃
- Weight: 6.8kg (with standard accessories)
- Dimensions: 198mm(L) × 82mm(W) × 82mm(H)
- Mounting type: Front flange & rear foot mounting
- Rod end thread: M16×1.5
- Protection rating: IP65 (standard), IP67 (optional)
- Lubrication: Pre-lubricated (Oil-free operation possible)
Heavy-duty triple-axis cylinder specifically engineered for environments requiring copper-free components. Features precision ground guide rods (H5 tolerance) and dual linear bearings for exceptional moment resistance. The nickel-plated piston rod and anodized body provide enhanced corrosion resistance in chemical or high-humidity applications.
- Semiconductor wafer handling systems
- Pharmaceutical production lines (GMP environments)
- Marine equipment actuators
- Food packaging machinery
- Lithium battery assembly automation
Installation note:
Requires precise parallel alignment (±0.1mm/m) during mounting.
Use only copper-free grease (Molykote EM-50L recommended) for maintenance.
Maximum side load capacity: 180N at full extension.
- Minimum operating speed: 30mm/s
- Maximum speed: 800mm/s (with cushion adjustment)
- Repeat positioning accuracy: ±0.05mm
- Service life: 5,000km (under standard load conditions)
| Property | Property Value |
|---|---|
| sku | B52-TCL50X60S |
