Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-147X290
AirTAC BAQK50SAAA-147X290 Clamp Type Pin Cylinder Specifications
- Model: BAQK50SAAA-147X290
- Type: Double-acting clamp pin cylinder with magnetic piston
- Bore size: 50mm
- Stroke: 147mm
- Total length (extended): 290mm ±1.5mm
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable air cushion at both ends
- Mounting type: Front flange with precision alignment pins
- Port size: M5x0.8 (G1/8 adapter optional)
- Piston rod thread: M16x1.5
- Operating temperature: -10℃ to 80℃
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Protection rating: IP54 (standard)
- Weight: 2.8kg ±3% (without accessories)
- Dimensions (W×H×D): 75mm × 75mm × 290mm
High-rigidity clamp cylinder designed for precision positioning with integrated alignment pins that eliminate mounting deflection. Features anti-rotation mechanism and reinforced guide structure capable of withstanding 30N·m lateral torque. Includes built-in magnet for position sensing compatibility. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Robotic welding fixture clamping
- CNC machine tool workpiece positioning
- Automated assembly line pallet locking
- Precision mold alignment systems
- Semiconductor handling equipment
Installation note:
Use torque wrench (14-16N·m) for mounting bolts. Lubricate with ISO VG32 hydraulic oil
during initial installation. Avoid side load exceeding 10% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-147X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
