Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-148X290
AirTAC BAQK50SAAA-148X290 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA-148X290
- Type: Double-acting clamp cylinder with mechanical lock
- Bore size: Ø50mm
- Stroke: 290mm
- Operating pressure: 0.1–1.0 MPa
- Piston speed: 50–800 mm/s
- Port thread: G1/8 (NPT1/8 optional)
- Piston rod material: Stainless steel (SUS304)
- Cylinder tube: Hard anodized aluminum alloy
- Locking force: 2,800N max @0.63MPa
- Temperature range: -10℃ to 80℃
- Weight: 3.2kg (dry, without accessories)
- Dimensions: 362mm(L) × 78mm(W) × 78mm(H)
- Buffer type: Adjustable rubber cushion
- Mounting style: Standard ISO 15552 front flange
Heavy-duty clamp cylinder featuring dual-piston design with integrated mechanical locking mechanism. The nickel-plated piston rod and precision honed cylinder tube ensure smooth operation under high lateral loads. Includes wear-resistant polyurethane seals and dust-resistant wiper ring. Requires filtered air (5-50μm) with lubrication (ISO VG32 recommended).
- Fixture positioning in CNC machining centers
- Workpiece clamping in automotive welding lines
- Mold locking in injection molding machines
- Heavy load handling in robotic palletizers
- Press brake tooling fixation systems
Installation note:
Ensure proper alignment of clamp pins before activation. Lubricate guide rods monthly with lithium soap grease.
Max permissible side load: 15% of axial thrust. Always depressurize before manual override.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-148X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
