Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-158X290
AirTAC BAQK50SAAA-158X290 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA-158X290
- Type: Double-acting clamp cylinder with magnetic piston
- Bore size: Ø50 mm
- Stroke: 290 mm
- Rod diameter: Ø16 mm
- Operating pressure: 0.1–1.0 MPa
- Clamping force: 1,570 N @ 0.5 MPa
- Mounting type: Front flange with reinforced base (158mm span)
- Cushioning: Adjustable air cushion (both ends)
- Seal material: NBR + Polyurethane
- Ambient temperature: -10℃ to 80℃
- Weight: 6.8 kg (with accessories)
- Dimensions: 158mm(W) × 50mm(H) × 582mm(L) (extended length)
- Port size: G1/4 (BSPP thread)
- Position detection: Built-in magnet for sensor mounting
- ISO standard: 15552 compliant
Heavy-duty clamping cylinder with precision-ground rod and anti-rotation mechanism, designed for high-moment load applications. Features triple-lip rod seal for extended lifespan in dusty environments. The reinforced flange base allows direct mounting to 20mm thick machine frames. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Automotive welding fixture clamping
- Die-casting machine mold locking
- Press tool positioning systems
- Heavy workpiece palletizing arms
- Plastic injection molding ejectors
Installation note:
Lubricate rod with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3mm minimum clearance between clamp base and mounting surface for thermal expansion.
Use locknuts with 35-40 N·m torque during assembly.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-158X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
