Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-159X290
AirTAC BAQK50SAAA-159X290 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA-159X290
- Type: Double-acting clamp cylinder with magnetic piston
- Bore size: Ø50 mm
- Stroke: 290 mm (extended length 159mm + stroke)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting: Standard ISO 15552 foot mounting
- Port size: G1/8 (NPT1/4 optional)
- Piston rod thread: M16×1.5
- Material: Aluminum alloy body, CR12MoV hardened piston rod
- Weight: 3.8 kg ±5% (without accessories)
- Dimensions:
- Length (retracted): 447 mm
- Width (body): 65 mm
- Height (mounting base): 105 mm
- Position detection: Built-in magnet for sensor mounting
- Lubrication: Pre-lubricated (DOP-free oil)
Heavy-duty clamp cylinder featuring enhanced lateral load capacity through integrated pin-lock mechanism. The hexagonal body design prevents rotation during operation, with precision-ground piston rod offering 20% higher buckling resistance than standard models. Requires filtered air (5-50μm) with 1-5 mg/m³ oil content.
- Vertical press tooling in automotive welding lines
- Pallet clamping in CNC machining centers
- Fixture locking for robotic assembly stations
- Mold securing in injection molding machines
- Position holding in material handling systems
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical applications exceeding 45° angle,
use external guide mechanisms. Lubricate piston rod weekly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-159X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
