Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-179X340
AirTAC BAQK50SAAA-179X340 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA-179X340
- Type: Double-acting clamp-type pin cylinder
- Bore size: 50mm
- Stroke: 340mm (179mm rod extension)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Buffer type: Adjustable hydraulic cushion (both ends)
- Mounting style: Standard ISO/VDMA base mounting
- Port size: M5×0.8 (1/8")
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal material: NBR + PU combination
- Weight: 3.8kg ±2%
- Dimensions:
- Body length: 534mm (full extension)
- Base width: 72mm
- Overall height: 62mm
- Mounting hole spacing: 60×60mm
Heavy-duty clamp cylinder featuring integrated locking mechanism with precision ground pins, designed for high moment load applications. The hardened guide rods (HRC 45-50) provide exceptional rigidity during clamping operations. Includes wear-resistant composite seals and IP67 protection rating for harsh environments. Requires 5μm filtered air with ISO 8573-1:2010 class 3.4.3 air quality.
- Fixture positioning in CNC machining centers
- Pallet clamping systems for automated assembly lines
- Mold locking in injection molding machines
- Heavy workpiece securing in welding jigs
- Press tool alignment mechanisms
Installation note:
Maintain horizontal orientation for optimal pin engagement. Apply ISO VG32 hydraulic oil
through air line lubricator (1 drop/m³). Perform weekly pin lubrication with EP2 grease
during high-cycle operations (>5,000 cycles/day).
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-179X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
