Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-197X340
AirTAC BAQK50SAAA-197X340 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA-197X340
- Type: Double-acting clamp cylinder with integrated mounting pins
- Bore size: 50mm (ISO 6432 standard)
- Stroke: 197mm ±1mm tolerance
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Cushioning: Adjustable rubber buffers (front/rear)
- Port size: G1/8 (ISO 228-1)
- Piston rod thread: M16×1.5 (Grade 12.9 hardened steel)
- Mounting: Front flange with 4×M8 tapped holes (72mm square pattern)
- Material: Aluminum alloy barrel (anodized), CR12MoV piston rod
- Seals: NBR (standard), optional FKM for high temps
- Temperature range: -10℃ to 80℃ (NBR seals)
- Weight: 6.8kg ±3% (with mounting hardware)
- Dimensions: 340mm(L) × 88mm(W) × 88mm(H)
- Rod end: Female threaded with anti-rotation flats
- Max thrust: 1,963N @ 0.63MPa
Heavy-duty clamp cylinder designed for precision fixturing applications requiring rigid mounting and anti-torsion stability. Features dual guide pins (Ø16h6 tolerance) for lateral force resistance up to 1,200N. Pre-lubricated for maintenance-free operation with integrated wear bands for smooth cycling. Requires filtered air (5-40μm) with recommended 1-3 cSt viscosity oil mist lubrication.
- CNC machine tool clamping systems
- Automotive welding fixture positioning
- Die-casting mold locking mechanisms
- Robotic arm end-effector tooling
- Semiconductor wafer handling stages
Installation tip:
Use precision shims (0.02mm grade) between mounting surface and flange to ensure
perpendicular alignment. Apply 24-28 N·m torque to M8 mounting bolts in cross pattern.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-197X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
