Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-249X340
AirTAC BAQK50SAAA-249X340 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA-249X340
- Type: Double-acting clamp-type rodless cylinder
- Bore size: Ø50mm (±0.1mm tolerance)
- Stroke: 249mm (non-adjustable)
- Operating pressure: 0.1–0.9 MPa (1–9 bar)
- Max thrust: 1570N at 0.63MPa (push/pull)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to +80℃
- Buffer type: Adjustable hydraulic cushioning
- Seal material: Nitrile rubber (NBR) with wear-resistant guide rings
- Mounting: ISO 15552 standard flange (MF1 pattern)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Rod end: M16x1.5 external thread
- Weight: 2.85kg (without accessories)
- Dimensions: 340mm(L) × 78mm(W) × 62mm(H)
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP54 (standard seals)
High-rigidity rodless cylinder with integrated mechanical clamp mechanism, featuring anti-rotation guidance and T-slot mounting surface. The twin-piston design eliminates lateral torque for precise linear motion. Requires filtered air (5μm+ oil mist recommended) and features chrome-plated piston rod with scratch-resistant coating.
- Precision workpiece positioning in CNC pallet systems
- Vertical lifting mechanisms for glass panel handling
- Clamping fixtures for automotive welding robots
- Cartesian robot Z-axis drives in packaging machinery
- Semiconductor wafer transfer systems
Installation note:
Mount on flat surface with 0.02mm/m alignment tolerance. Lubricate guide rails with ISO VG32 hydraulic oil during initial setup. Clamp force requires adjustment via hex socket (4Nm torque limit) after stroke positioning.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-249X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
