Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-158X310
$467.56
Regular price
$475.06
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
BAQK50SAAA2-158X310
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Titanium alloy-plated pin surfaces for enhanced wear resistance;
3. Integrated metal wiper ring on front cover effectively removes debris and chips from cylinder rod;
4. Multi-position mounting capability with quadruple-sided mounting surfaces on unit body;
5. Perimeter sensor grooves enable seamless proximity sensor integration.
Category: Clamp Pin Cylinder | Brand: AIRTAC | Series: BAQK
Maintenance Tip:
Lubricate guide pins monthly with ISO VG32 hydraulic oil. Avoid angular
misalignment exceeding 0.5° during installation. Maximum side load capacity:
850N at full extension.
AirTAC BAQK50SAAA2-158X310 Clamp-Type Pin Cylinder Specifications
- Model Code: BAQK50SAAA2-158X310
- Bore Size: 50mm
- Stroke: 310mm (customizable 10-1000mm)
- Operation Type: Double-acting
- Working Pressure: 0.05-1.0 MPa
- Mounting Style: Front flange with reinforced clamp band
- Rod End: M20x1.5 male thread (stainless steel)
- Cushioning: Adjustable air cushion (both ends)
- Ambient Temp: -10℃ to 70℃ (NBR seals)
- Port Size: G1/4 (BSPP)
- Piston Material: Hard anodized aluminum alloy
- Rod Protection: Chrome-plated with wiper ring
- Weight: 3.8kg ±2% (excluding accessories)
- Dimensions:
- Extended Length: 702mm
- Retracted Length: 392mm
- Body Diameter: 64mm
- Mounting Flange: 115×115mm
Heavy-duty clamp cylinder with integrated anti-rotation pin mechanism, engineered for precision linear motion under high lateral load conditions. Features dual-lock clamp band for vibration resistance and zero backlash positioning. Requires 40μm filtered lubricated air (ISO 8573-1).
Industrial Applications:
- Automotive welding fixture positioning
- Die-casting machine core-pulling mechanisms
- Sheet metal bending tool clamping
- Plastic injection molding ejector systems
- CNC rotary table locking devices
Maintenance Tip:
Lubricate guide pins monthly with ISO VG32 hydraulic oil. Avoid angular
misalignment exceeding 0.5° during installation. Maximum side load capacity:
850N at full extension.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-158X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
