Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-178X360
AirTAC BAQK50SAAA2-178X360 Clamp-Type Pin Cylinder Specifications
- Model Code: BAQK50SAAA2-178X360
- Series: BAQK (Clamp-Type Rodless Cylinder)
- Bore Size: Ø50 mm
- Stroke: 178 mm
- Total Length: 360 mm (including end caps)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Buffer Type: Adjustable hydraulic cushion (both ends)
- Port Size: M5x0.8 (standard) / Optional NPT1/8
- Mounting Style: Dual horizontal mounting slots (base plate optional)
- Piston Material: Aluminum alloy with hard anodizing
- Rod Material: Chrome-plated steel (SUJ2 equivalent)
- Seal Type: NBR + PU combination seals
- Repeat Positioning Accuracy: ±0.1 mm
- Max. Piston Speed: 500-700 mm/s (with cushioning)
- Weight: 3.2 kg (±5%)
- Dimensions (W×H×L): 66mm × 64mm × 360mm
A high-rigidity rodless cylinder featuring dual guide rods and anti-rotation mechanism, designed for precision linear motion under heavy side loads. The clamp-type design integrates slide block locking with 0.01mm backlash control, making it ideal for vertical Z-axis applications. Includes built-in magnet for position sensing compatibility.
- PCB handling robots in electronics assembly
- Glass panel transfer systems (LCD manufacturing)
- Die-casting machine core-pulling mechanisms
- Automated welding fixture positioning
- Packaging machine vertical lift modules
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended) every 3 months or 500km stroke.
Avoid lateral impact forces exceeding 200N. For vertical mounting, use auxiliary support brackets when stroke exceeds 150mm.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-178X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
