Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-199X360
AirTAC BAQK50SAAA2-199X360 Clamping Pin Cylinder Specifications
- Model: BAQK50SAAA2-199X360
- Type: Double-acting clamping pin cylinder
- Bore size: Ø50 mm
- Stroke: 199 mm (extended length: 360 mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Square body with through-hole mounting
- Port size: 1/4" NPT (G1/4 optional)
- Temperature range: -20℃ to 80℃
- Rod material: Hard chrome-plated steel
- Seal material: NBR + PU hybrid seals
- Protection rating: IP54 (standard wiper)
- Weight: 3.8 kg ±2%
- Dimensions: 360mm(L) × 72mm(W) × 72mm(H) (at full extension)
- Max thrust: 1,962N @ 0.63 MPa
High-rigidity clamping cylinder featuring dual anti-rotation pins (Ø12mm hardened steel) for precise tooling alignment. The reinforced square body design minimizes deflection under side loads, with anodized aluminum construction resisting industrial contaminants. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Fixture locking in CNC machining centers
- Pallet clamping in automated assembly lines
- Tool changer positioning for robotic arms
- Mold clamping in injection molding machines
- Precision alignment in optical equipment assembly
Installation note:
Mount on machined flat surface (Ra≤3.2μm). Lubricate guide pins monthly with ISO VG32 hydraulic oil.
Avoid continuous side loads exceeding 200N. Allow 15mm clearance around clamp pins for maintenance.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-199X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
