Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-247X360
AirTAC BAQK50SAAA2-247X360 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA2-247X360
- Type: Double-acting clamp pin cylinder
- Bore size: Ø50 mm
- Stroke: 247 mm
- Rod diameter: Ø20 mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Port size: M5×0.8 (G1/8 optional)
- Mounting type: Clamp-style with integrated mounting slots
- Seal material: Polyurethane (NBR optional)
- Weight: 3.8 kg ±2%
- Dimensions:
- Length (retracted): 502 mm
- Width (body): 72 mm
- Height (with clamp): 98 mm
- Protection rating: IP54 (standard)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil)
Heavy-duty clamp-type cylinder designed for high moment load applications. Features integrated mounting grooves for secure clamping stability and optional anti-rotation pin (360° positionable). Precision-ground rod with hard chrome plating ensures extended service life in harsh environments.
- Press machine tooling positioning
- Automated welding fixture clamping
- Die casting machine core-pulling mechanisms
- Heavy conveyor gate actuation
- Paper processing equipment tension control
Installation note:
Apply 24-28 N·m torque for clamp screws. Use shim washers when mounting
on uneven surfaces. For vertical installations, position exhaust ports downward
to prevent condensation accumulation.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-247X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
