Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-249X360
AirTAC BAQK50SAAA2-249X360 Clamp-Type Pin Cylinder Specifications
- Model Code: BAQK50SAAA2-249X360
- Type: Double-acting clamp cylinder with auto-grip mechanism
- Bore size: Ø50 mm
- Stroke: 249 mm (customizable up to 500mm)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 70℃
- Port size: G1/8 (BSPP thread)
- Cushioning: Adjustable hydraulic shock absorber
- Mounting style: Standard ISO 15552 front flange with rear foot
- Rod material: Hard chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal type: NBR + Polyurethane hybrid seals
- Weight: 3.8 kg ±2% (without accessories)
- Dimensions:
- Extended length: 702 mm
- Retracted length: 453 mm
- Body width: 80 mm
- Mounting height: 50 mm
- ISO certification: 6431/VDMA 24562 compliant
High-moment clamp cylinder engineered for precision gripping applications, featuring enhanced lateral load capacity through integrated guide rods. The X360 suffix indicates special 360° rotatable clevis mount. Requires 5μm filtered air with ISO VG32 lubricant recommendation for high-cycle operations.
- Automotive welding fixture positioning
- CNC machine tool clamping systems
- Heavy-load pallet locking in AS/RS
- Press brake back gauge manipulation
- Glass handling vacuum cup arrays
Maintenance tip:
Lubricate guide pins monthly with EP2 grease and inspect clamp force every 50,000 cycles.
Avoid side impacts exceeding 200N during operation.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-249X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
