Airtac BC Series Air Treatment Combination (Filter Regulator Lubricator) BC30001
2、Press-in self-locking mechanism prevents external interference from altering preset pressure values;
3、Minimal pressure drop with optimized condensate separation efficiency;
4、Transparent sight window enables real-time visual monitoring of lubrication dosage;
5、Available in standard configuration and low-pressure variant (maximum adjustable pressure 0.4MPa).
Category: Air Treatment Units, Brand: Airtac, Series: BC
AirTAC BC30001 Triple Unit (FRL) Technical Specifications
- Model: BC30001
- Type: Filter-Regulator-Lubricator combination
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.05–0.85 MPa
- Maximum flow rate: 1,500 L/min (ANR)
- Filtration grade: 40μm (5μm optional with micro-filter)
- Lubricator oil capacity: 80cm³
- Adjustable pressure range: 0.05–0.85 MPa
- Temperature range: -5℃ to 60℃ (non-freezing)
- Body material: Aluminum alloy (filter bowl: PC composite)
- Weight: 0.8 kg (empty) / 0.95 kg (with oil)
- Dimensions: 165mm(L) × 70mm(W) × 70mm(H)
- Drain type: Manual/auto drain options
- Pressure gauge: Built-in 40mm dial (MPa scale)
Integrated pneumatic conditioning unit combining precision filtration, pressure regulation, and aerosol lubrication. Features a shatter-resistant polycarbonate bowl with safety guard and corrosion-resistant aluminum body. The 360° rotatable bracket enables flexible installation in confined spaces. Includes pressure relief lock mechanism to prevent accidental adjustment.
- Pneumatic tool air preparation systems
- Packaging machinery main air lines
- Industrial automation control circuits
- CNC machine pneumatic subsystems
- Food processing equipment (oil-free version available)
Maintenance protocol:
Replace filter element every 2,000 operational hours. Lubricator requires
ISO VG32 turbine oil refill when oil level drops below 1/3 capacity.
Bowl should face away from operator during installation.
| Property | Property Value |
|---|---|
| sku | BC30001 |
| Port Size | PT3/8 |
