Airtac BD Female-Male Straight Connector BD0104-S
AirTAC BD0104-S Male-Female Straight Threaded Connector Specifications
- Model: BD0104-S
- Thread Type: Male NPT 1/4" (external) × Female NPT 1/4" (internal)
- Material: Lead-free brass (CuZn39Pb0.5) with nickel plating
- Surface Treatment: Electrochemical oxidation for corrosion resistance
- Pressure Rating: 0.05-1.5 MPa (7-217 psi)
- Temperature Range: -20℃ to 120℃ (-4°F to 248°F)
- Seal Type: Metal-to-metal seal with optional PTFE tape compatibility
- Hex Size: 17mm wrench flat
- Weight: 22g ±0.5g
- Dimensions: 32mm(Total Length) × 17mm(Width across flats) × 14mm(Hex Height)
- Thread Engagement Depth: 9.5mm (female side), 10.2mm (male side)
- Max Torque: 25 N·m (18.4 lb-ft)
- Compliance: RoHS 2.0 compliant
A bidirectional flow connector featuring precision-machined tapered threads for leak-free connections in high-vibration environments. The asymmetrical design allows direct conversion between male and female NPT ports without adapters. Internal flow path maintains 4.2mm minimum bore diameter to minimize pressure drop.
- Pneumatic cylinder port conversion in robotic arms
- Compressed air line extensions for CNC machinery
- Hydraulic test bench manifold assemblies
- Vacuum system component interfacing
- Industrial laser cooling circuit installations
Installation note:
Apply thread sealant to male threads only. Clockwise rotation tightens both connections simultaneously.
Avoid overtightening beyond 1.5 turns past finger-tight position. Inspect thread engagement depth using
the machined witness groove.
| Property | Property Value |
|---|---|
| sku | BD0104-S |
