Airtac BD Female-Male Straight Connector BD0304
AirTAC BD0304 Male-Female Straight Threaded Connector Specifications
- Model: BD0304
- Thread type: G1/8 (Male) & PT1/8 (Female)
- Material: Brass with nickel plating
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -5℃ to 120℃
- Proof pressure: 3.0 MPa
- Burst pressure: 6.0 MPa
- Seal material: NBR (Nitrile) O-ring
- Surface roughness: Ra ≤1.6μm
- Weight: 12.5g ±0.3g
- Dimensions: 24mm(L) × 24mm(W) × 24mm(H)
- Compliance: RoHS compliant
- Thread engagement depth: 8mm (male), 9mm (female)
A precision-machined bidirectional connector featuring corrosion-resistant nickel plating and dual-thread design for secure pneumatic line transitions. The chamfered edges prevent O-ring damage during installation, while the hexagonal body allows standard wrench operation. Rated for 500,000+ actuation cycles.
- Transition between metric and pipe threads in compact manifolds
- Pneumatic tool air supply line connections
- Vacuum system component interfacing
- Medical gas equipment tubing adapters
- Automated assembly line quick-connect systems
Installation protocol:
Apply PTFE tape on male threads using clockwise winding pattern.
Tighten to 12-15 N·m torque with backup wrench on female side.
Perform pressure test at 110% working pressure after installation.
| Property | Property Value |
|---|---|
| sku | BD0304 |
