Airtac BKC Bulkhead Lock Nut Union BKC0425-M3
AirTAC BKC0425-M3 Locknut Straight Connector Specifications
- Model: BKC0425-M3
- Type: Compression tube fitting with locknut design
- Thread specification: M3×0.5 external thread
- Tube compatibility: 4mm OD (outer diameter) pneumatic tubing
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) O-ring
- Operating pressure: 0.5-8 MPa (72-1160 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 14.5±0.3g
- Dimensions: 25mm(L) × 12mm(W) × 12mm(H)
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Vibration resistance: ≤5G acceleration (10-2000Hz)
- Certification: RoHS compliant
High-density compression fitting featuring dual-seal structure with front-end O-ring and rear metal-to-metal contact. The hexagonal body allows tool-assisted tightening (recommended torque: 0.4-0.6N·m). Anti-vibration locknut prevents loosening under pulsation conditions. Compatible with air, water, and inert gases.
- Miniature pneumatic circuit connections in robotics
- Medical device gas delivery systems
- Precision instrument air supply lines
- 3D printer pneumatic extruder connections
- Laboratory analytical equipment tubing interfaces
Installation guide:
Insert tube fully until it bottoms out before tightening. Perform pressure test at 1.5× working pressure after assembly. Replace O-ring every 5,000 connection cycles or 2 years (whichever comes first).
| Property | Property Value |
|---|---|
| sku | BKC0425-M3 |
