Airtac BKC Bulkhead Lock Nut Union BKC0604-03-S
AirTAC BKC0604-03-S Locknut Straight Connector Specifications
- Model: BKC0604-03-S
- Type: Threaded locknut straight connector (female thread to tube)
- Body material: Brass (surface nickel-plated)
- Thread specification: M6×1.0 external thread (ISO 1179-2 standard)
- Tube compatibility: Ø4mm outer diameter pneumatic tubing
- Operating pressure: 0.05–1.5 MPa
- Temperature range: -20℃ to 80℃ (with NBR seals)
- Seal material: NBR (Nitrile rubber) standard
- Anti-rotation design: Hexagonal body with 8mm wrench flat
- Leakage rate: ≤0.1 NL/min under rated pressure
- Protection rating: IP40 (dust protected)
- Weight: 8.5g ±0.3g
- Dimensions: 16mm(L) × 12mm(W) × 12mm(H)
High-pressure resistant connector featuring dual-seal structure with primary O-ring and secondary metal-to-metal contact. The knurled locknut enables tool-free installation while maintaining vibration resistance. Internal flow path optimized for minimal pressure drop (ΔP < 0.02 MPa @ 1.0 MPa).
- Pneumatic cylinder port connections in robotic arms
- Modular assembly of SMC-compatible air preparation units
- Vacuum system tubing interfaces for CNC machines
- Compressed air distribution in food packaging lines
- Laboratory instrument gas chromatography setups
Installation guidance:
Hand-tighten until snug (≈1.5 N·m torque), then apply 1/4 turn with wrench.
Ensure tube is cut square and deburred before insertion. Maximum reconnection
cycles: 5 times recommended for leak-proof performance.
| Property | Property Value |
|---|---|
| sku | BKC0604-03-S |
