Airtac BKC Bulkhead Lock Nut Union BKC0805-03-S
AirTAC BKC0805-03-S Locknut Straight Fitting Specifications
- Model: BKC0805-03-S
- Series: BKC Pneumatic Fittings
- Thread Type: M5×0.8 (Metric Fine Thread)
- Seal Material: HNBR (Hydrogenated Nitrile)
- Body Material: SUS303 Stainless Steel
- Operating Pressure: 0.05–1.5 MPa (7–217 psi)
- Temperature Range: -20℃ to 150℃
- Surface Treatment: Electrolytic Polishing
- Tube OD Compatibility: 8mm (PU/Nylon Tubing)
- Thread Engagement: 4 full turns minimum
- Weight: 18g ±0.5g
- Dimensions: 30mm(L) × 8mm(Dia) × 8mm(Port Width)
- Vibration Resistance: ≤10Hz frequency, 1.5mm amplitude
- Leakage Rate: <3×10⁻² Pa·m³/s (He leak tested)
High-precision stainless steel push-to-connect fitting with triple sealing structure (metal-to-metal primary seal + dual elastomer secondary seals). Features 360° rotatable collar for tool-free installation in confined spaces. The anti-vibration locknut design prevents accidental disconnection in high-cycle applications.
- Semiconductor wafer handling robots
- High-cycle pneumatic gripper systems
- Food processing equipment (NSF compliant)
- Vacuum line connections in analytical instruments
- Hydraulic test bench manifolds
Installation protocol:
Cut tubing square with dedicated cutter, deburr thoroughly, and insert until
audible "click". Perform 2-3mm pull test to verify positive engagement.
For vacuum applications, apply silicone-free lubricant to HNBR seals.
| Property | Property Value |
|---|---|
| sku | BKC0805-03-S |
