Airtac BKC Bulkhead Lock Nut Union BKC0806-01
AirTAC BKC0806-01 Locknut Straight Connector Specifications
- Model: BKC0806-01
- Type: Push-to-connect locknut straight connector
- Material: Brass with nickel plating (corrosion-resistant)
- Thread Standard: Metric (M5×0.8 thread)
- Tube Compatibility: 8mm OD (6mm ID) polyurethane/nylon tubing
- Max Working Pressure: 1.5 MPa (217 psi)
- Temperature Range: -20℃ to 80℃
- Seal Material: NBR (Nitrile) rubber
- Weight: 15g ±0.5g
- Dimensions: 20mm(L) × 12mm(W) × 12mm(H)
- Surface Hardness: HV200-250
- Leakage Rate: <0.1 mL/min under max pressure
- Vibration Resistance: 10-2000Hz, 15G acceleration
Precision-engineered pneumatic connector featuring tool-free installation and positive lock mechanism. The dual-stage sealing system combines O-ring compression with collet grip technology, ensuring leak-proof connections even under pulsating pressure conditions. Anti-vibration design prevents tubing slippage in dynamic environments.
- Modular pneumatic circuit assembly lines
- Robotic arm end-effector tooling
- CNC machine lubrication systems
- Semiconductor cleanroom equipment
- Automated packaging machinery
Installation protocol:
Insert tubing until audible click, then pull back gently to verify engagement.
For maintenance: Push collet collar fully forward before tube removal.
Maximum recommended reconnection cycles: 50 times.
| Property | Property Value |
|---|---|
| sku | BKC0806-01 |
