Airtac BKC Bulkhead Lock Nut Union BKC0806-01-S
AirTAC BKC0806-01-S Locknut Straight Connector Specifications
- Model: BKC0806-01-S
- Type: Locknut-style straight pneumatic fitting
- Thread Standard: Metric (M5×0.8 female thread)
- Material: Brass with nickel plating (CuZn39Pb3)
- Seal Material: NBR (Nitrile) rubber
- Operating Pressure: 0-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Tube Compatibility: Ø8mm outer diameter (6mm inner diameter)
- Surface Hardness: HV 200±20 (nickel layer)
- Tightening Torque: 1.2-1.5 N·m recommended
- Weight: 48±2g
- Dimensions: 30mm(L) × 15mm(W) × 15mm(H)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Heavy-duty straight connector featuring dual-seal structure with primary O-ring and secondary metal-to-metal contact. The hexagonal locknut design enables tool-assisted tightening for vibration-prone environments. Electroless nickel plating provides corrosion resistance against water and mild chemicals.
- Pneumatic cylinder port connections
- Modular assembly in automation equipment
- High-vibration machinery (e.g., stamping presses)
- Plastic injection molding air circuits
- Vacuum system tubing interfaces
Installation protocol:
Hand-tighten until snug, then apply 1/4 turn with a 10mm wrench.
Avoid overtightening which may deform the ferrule. Always install
with tube fully inserted until it bottoms out.
| Property | Property Value |
|---|---|
| sku | BKC0806-01-S |
