Airtac BKC Bulkhead Lock Nut Union BKC0806-02
AirTAC BKC0806-02 Locknut Straight Connector Specifications
- Model: BKC0806-02
- Type: Reusable locknut-style straight fitting
- Thread specification: M8×1.0 (external) / M5×0.8 (internal)
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) O-ring
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 80℃
- Tube compatibility: Ø6mm polyurethane/nylon tubing
- Surface hardness: HV200-250 (plated layer)
- Torque specification: 1.2-1.5 N·m (recommended assembly)
- Weight: 15g ±0.5g
- Dimensions: 40mm(L) × 12mm(Ø) × 12mm(Hex)
- Standards compliance: ISO 8434-1 (DIN 2353)
- Corrosion resistance: 96hrs salt spray test passed
Heavy-duty pneumatic connector featuring triple-seal technology with primary metal-to-metal sealing, secondary O-ring compression, and tertiary thread locking. The knurled locknut enables tool-free installation while maintaining vibration resistance up to 15G acceleration. Compatible with ISO pneumatic systems requiring frequent maintenance access.
- Robotic arm pneumatic gripper connections
- CNC machine tool coolant line junctions
- Food processing equipment air supply lines
- Semiconductor manufacturing vacuum systems
- Railway braking system piping networks
Installation protocol:
Hand-tighten until snug, then apply 1/4 turn with wrench.
Always install with at least 2 full threads engaged.
Replace O-ring every 5,000 cycles or 2 years (whichever comes first).
| Property | Property Value |
|---|---|
| sku | BKC0806-02 |
