Airtac BKC Bulkhead Lock Nut Union BKC1065-02-S
AirTAC BKC1065-02-S Locknut Straight Connector Specifications
- Model: BKC1065-02-S
- Type: Metric thread locknut straight connector
- Thread specification: M5×0.8 female thread (both ends)
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) O-ring
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 80℃ (non-condensing)
- Port size: For Ø6mm OD tubing
- Weight: 38g ±2g
- Dimensions: 40mm(L) × 12mm(Dia) × 12mm(Thread length)
- Surface roughness: Ra ≤3.2μm (sealing surfaces)
- Certification: RoHS compliant
Precision-engineered straight connector with integrated locknut mechanism, designed for secure tubing connections in high-vibration environments. Features dual sealing surfaces with self-aligning capability and corrosion-resistant nickel plating. Compatible with air, water, and neutral gases.
- Pneumatic cylinder manifold connections
- CNC machine tool coolant lines
- Semiconductor equipment gas delivery systems
- Robotic arm pneumatic gripper circuits
- Medical device compressed air networks
Installation guide:
Hand-tighten until resistance is felt, then apply 1/4 turn with wrench.
Always use backup wrench on hex body during assembly.
Maximum torque: 2.5 N·m.
Test with 0.6 MPa air pressure after installation.
| Property | Property Value |
|---|---|
| sku | BKC1065-02-S |
