Airtac BPC Metal Straight Connector BPC1204
2. Features excellent flow characteristics achieving equivalent flow capacity to tube inner diameter;
3. Tool-free push-to-connect design enables fast tube installation, with secure and durable pneumatic tube connections;
4. M5 metric threads with integrated sealing washers ensure leak-free threaded connections;
5. Nickel-plated body provides corrosion resistance and contamination prevention, extending service life;
6. Full-metal construction ensures reliable performance in high-temperature environments.
Category: Threaded Straight Connectors , Brand: AirTAC , Series: BPC
AirTAC BPC1204 Metal Straight Thread Connector Specifications
- Model: BPC1204
- Type: Metric straight thread connector (male to female)
- Material: Brass with nickel-plated finish
- Thread standard: M5×0.8 (internal) / M5×0.8 (external)
- Hose compatibility: 4mm OD pneumatic tubing
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) O-ring
- Vibration resistance: ≤5Hz @ 2.5mm amplitude
- Protection rating: IP40 (dust protected)
- Weight: 14.5±0.3g
- Dimensions: 30mm(L) × 12mm(W) × 12mm(H)
Precision-machined brass connector featuring 45° inverted flare seat for leak-free connections in high-vibration environments. The stepped thread design ensures smooth engagement while preventing overtightening. Nickel plating provides corrosion resistance against moisture and mild chemicals.
- Robotic arm pneumatic tool changers
- CNC machine coolant line junctions
- Packaging machine air nozzle clusters
- Laboratory instrument gas supply lines
- Electric vehicle brake air systems
Installation note:
Apply thread sealant only on male threads (not on sealing surfaces).
Torque specification: 0.8-1.2 N·m. Always perform pressure test
at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | BPC1204 |
| Port Size | 12mm |
| Connection Thread | PT 1/2 |
