Airtac BSED Clamping Double Acting Cylinder BSED32X300S
2. Enables positive locking at any intermediate position during stroke travel;
3. Precision-engineered locking system ensures engagement stability independent of piston movement direction.
Category: Double-acting cylinders, Brand: AirTAC, Series: BSED
AirTAC BSED Clamping Double Rod Cylinder BSED32X300S Specifications
- Model: BSED32X300S
- Type: Double rod cylinder with clamping mechanism
- Bore size: 32mm
- Stroke: 300mm
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: G1/8 (Rc1/8 optional)
- Piston speed: 50–800 mm/s
- Buffer type: Adjustable hydraulic cushion (both ends)
- Rod material: Chrome-plated carbon steel (STD) / Stainless steel (SSU option)
- Seal material: NBR (standard) / PU (optional)
- Mounting type: Basic fixed mounting (MF1) with multiple accessory options
- Weight: 3.2 kg (without accessories)
- Dimensions: 576mm(L) × 54mm(W) × 54mm(H) (fully extended)
- Rod diameter: 16mm (both rods)
- Max lateral load: 98N
- ISO standard: 15552 (VDMA 24562)
High-precision industrial cylinder featuring synchronized dual-rod movement with integrated mechanical clamping. The through-rod design ensures equal force distribution and position accuracy during extended stroke operations. Enhanced wear resistance through triple chrome plating on piston rods. Requires ISO 8573-1 class 3 or cleaner compressed air.
- Precision fixturing in CNC machining centers
- Simultaneous lifting mechanisms in assembly lines
- Material clamping in injection molding machines
- Synchronized positioning in semiconductor handling
- Parallel gripper actuation in robotics
Installation note:
Ensure proper alignment of clamping surfaces within ±0.5mm tolerance.
Lubricate with ISO VG32 hydraulic oil if used in high-cycle applications (>5 cycles/sec).
Maintain 20mm clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | BSED32X300S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | 27mm |
| Bore Diameter | <32 mm> |
| Stroke | 300mm |
| Static Holding Force | 600N |
