Airtac CDA Standard Solenoid Coil CDA080C
Category: Solenoid Valve Coils , Brand: AirTAC , Series: CDA
AirTAC CDA080C Standard Coil Technical Details
- Model: CDA080C
- Coil type: DC-operated solenoid
- Voltage range: 24VDC ±10%
- Power consumption: 2.2W ±10% (at 20℃)
- Insulation class: Class B (130℃)
- Duty cycle: Continuous (100% ED)
- Wire material: Copper enameled wire (H-class insulation)
- Terminal type: DIN43650 Form A connector
- Operating temperature: -5℃ to 120℃
- Protection rating: IP65 (coil housing)
- Inductance: 0.8H ±15% (DC24V)
- Resistance: 260Ω ±15% (at 20℃)
- Weight: 185g ±5g
- Dimensions: 42mm(L) × 35mm(W) × 32mm(H)
- Mounting orientation: Any (360° rotatable)
High-efficiency solenoid coil designed for AirTAC 4V/5V series valves. Features overcurrent protection design with thermal-resistant polymer housing. The encapsulated structure prevents moisture ingress while maintaining excellent heat dissipation through aluminum alloy core. Compatible with ISO4400 standard valve interfaces.
- Industrial automation control systems
- Plastic injection molding machines
- Textile machinery pneumatic circuits
- Semiconductor manufacturing equipment
- Automotive assembly line actuators
- Food processing pneumatic controls
Installation guidelines:
Ensure valve spool moves freely before energizing. Use M4 screws with 0.4-0.6Nm torque for secure mounting.
Maintain minimum 3mm clearance from heat sources. For extended lifespan, keep ambient temperature below 60℃.
Important:
Do not use AC power supply. Avoid oil contamination on coil surface.
Disconnect power before performing insulation resistance tests (min 50MΩ at 500VDC).
| Property | Property Value |
|---|---|
| sku | CDA080C |
| Standard Voltage | AC 110V |
| Coil Inner Diameter | 8.0MM |
