Airtac CM3HS Selector Mechanical Valve CM3HS06-P3
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
AirTAC CM3HS06-P3 Selector Mechanical Valve Technical Details
- Model: CM3HS06-P3 (Selector Series)
- Valve type: 3/2-way normally closed, mechanically actuated
- Port configuration: G1/8 (BSPP) or optional NPT1/8
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Flow capacity: Cv 0.12 / Kv 0.10
- Actuation force: 3.5N ±0.5N at roller contact point
- Mechanical life: ≥5 million cycles (no load)
- Seal material: Heat-resistant NBR (Nitrile) for ≤80℃
- Temperature tolerance: -20℃ to 80℃ (non-freezing)
- Body material: Anodized aluminum alloy (ADC12)
- Weight: 180g ±5g (without accessories)
- Dimensions: 50mm(L) × 30mm(W) × 60mm(H)
- Mounting orientation: Vertical (±15° tolerance)
- Exhaust options: Single or dual muffler (optional)
Manual override mechanical valve with roller lever mechanism, engineered for precise position sensing in automated machinery. Features anti-vibration locknut design and wear-resistant roller bearing, optimized for high-cycle cam follower applications. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particles).
- Cartesian robot end effector positioning
- Assembly line pallet stopper activation
- Textile machine thread tension control
- CNC tool changer safety interlocks
- Conveyor diverter gate actuation
Operational guidance:
Lubricate roller pivot monthly with ISO VG32 turbine oil.
Maintain 0.5-1mm cam clearance during adjustment.
Not recommended for lateral impact applications exceeding 5G force.
