Airtac CM3PP Mushroom Head Push Button Mechanical Valve CM3PP05Y
$21.16
Regular price
$28.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3PP05Y
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Product Description:**
1. The CM3B, CM3L, CM3V, and CM3R series require externally applied force for valve actuation, making them ideal for position detection or as limit switches.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
Installation guidelines:
Mount with 30mm clearance above button for full stroke engagement.
Lubricate pivot points with ISO VG32 hydraulic oil quarterly.
Avoid side-loading during actuation to prevent shaft misalignment.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
AirTAC CM3PP Convex Head Push Button Mechanical Valve CM3PP05Y Specifications
- Model: CM3PP05Y
- Type: 2-position 3-way normally closed (manual mechanical)
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.05–0.8 MPa
- Operating temperature: -5℃ to 60℃
- Flow capacity: 750 l/min (ANR)
- Actuation force: 3.5N ±0.5N
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR (nitrile rubber)
- Weight: 112g ±2g
- Dimensions: 38mm(L) × 28mm(W) × 54mm(H)
- Mounting type: Direct piping (no sub-base required)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Cycle life: ≥500,000 operations
Robust manual override valve with ergonomic convex button design, featuring tactile feedback and anti-slip grooves. The chrome-plated steel spring ensures consistent return force across temperature variations. Integrated dust shield prevents particulate ingress in harsh environments.
Typical Applications:
- Emergency stop override in pneumatic systems
- Manual mode switching for production line jigs
- Maintenance bypass in automated assembly machines
- Process control override in food packaging equipment
- Safety interlocks in press machinery
Installation guidelines:
Mount with 30mm clearance above button for full stroke engagement.
Lubricate pivot points with ISO VG32 hydraulic oil quarterly.
Avoid side-loading during actuation to prevent shaft misalignment.
| Property | Property Value |
|---|---|
| sku | CM3PP05Y |
| Position | 3-Port 2-Position |
| Port Size | M5 |
