Airtac CM3PP Mushroom Head Push Button Mechanical Valve CM3PP06-P4
$9.73
Regular price
$17.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3PP06-P4
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Product Description:**
1. The CM3B, CM3L, CM3V, and CM3R series require externally applied force for valve actuation, making them ideal for position detection or as limit switches.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
Installation guidelines:
Requires 1.5-3mm thick mounting panel. Apply thread sealant on port connections.
For vertical mounting, ensure yellow reset ring rotates freely without obstruction.
Test full travel monthly - actuator should click audibly when fully depressed.
2. The CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diverse actuator configurations to suit varying operational conditions.
3. Poppet valve design ensures superior sealing performance, responsive actuation, and maintenance-free operation (no lubrication required).
4. Flexible mounting orientations for simplified installation and integration.
5. The CM3L, CM3V, CM3R, and CM3Y series incorporate durable metal actuators for extended service life and enhanced operational reliability.
6. The CM3PMS and CM3PMX series are equipped with robust metal protective shrouds to safeguard the push button from accidental impacts and unintended actuation, ensuring safe and reliable performance.
**Classification:** Mechanical Valves **Brand:** AirTAC **Series:** CM3PP Convex Head Push Button Type
AirTAC CM3PP Push Button Mechanical Valve CM3PP06-P4 Technical Details
- Model: CM3PP06-P4
- Type: 3/2-way normally closed (manual reset)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa
- Actuation force: 3.5N ±0.5N
- Valve body material: PA66+30%GF (UL94 V-0 rated)
- Seal material: HNBR rubber (-20℃ to 120℃)
- Flow capacity: 500 NL/min (at 0.5 MPa)
- Weight: 128g ±5g
- Dimensions: 48mm(L) × 33mm(W) × 34mm(H)
- Temperature range: -20℃ to 80℃ (with silicone grease below 0℃)
- Mechanical life: ≥1,000,000 cycles
- Protection rating: IP67 (dust/water immersion resistant)
- Mounting options: Panel mount (8.5mm hole required)
Robust mushroom-head emergency stop valve with positive mechanical latching mechanism. Features anti-vibration lock design and dual-color position indicator (red/yellow). The extended actuator protrudes 15mm from mounting surface for blind operation. Compatible with ISO 13850 safety standards.
Industrial Applications:
- Emergency stop circuits in CNC machinery
- Safety interlocks for automated production lines
- Press machine two-hand control systems
- Robotic cell access gates
- Packaging equipment jam recovery systems
Installation guidelines:
Requires 1.5-3mm thick mounting panel. Apply thread sealant on port connections.
For vertical mounting, ensure yellow reset ring rotates freely without obstruction.
Test full travel monthly - actuator should click audibly when fully depressed.
| Property | Property Value |
|---|---|
| sku | CM3PP06-P4 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
