Airtac CPV10M Mounting Base CPV10MJ03-10F
$28.60
Regular price
$36.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ03-10F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation note:
Apply 0.3-0.5Nm torque during bolt tightening. Use stainless steel
washers (M6 size recommended) when mounting on ferrous surfaces
to prevent galvanic corrosion. Alignment pins should face load direction.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-10F Mounting Base Specifications
- Model: CPV10MJ03-10F
- Compatibility: Designed for CPV10M series cylinders
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Black anodized
- Mounting type: Horizontal/vertical dual-orientation
- Bolt hole size: M6×1.0 (4 holes)
- Center distance: 30mm (horizontal) × 25mm (vertical)
- Load capacity: Max 50N·m torque resistance
- Weight: 185g ±5g
- Dimensions: 58mm(L) × 34mm(W) × 22mm(H)
- Operating temperature: -20℃ to 80℃
- Vibration resistance: ≤10Hz @ 2mm amplitude
- Corrosion protection: MIL-STD-810G salt spray tested
Precision-machined mounting base featuring anti-rotation grooves and dual mounting planes. Includes integrated shock-absorbing pads (Shore A70) for vibration damping. Compatible with ISO 15552 mounting standards, with laser-etched alignment markers for quick installation.
Typical Applications:
- Modular pneumatic assembly systems
- Robotic end-effector mounting
- Conveyor line pusher mechanisms
- Automated packaging machinery
- Semiconductor handling equipment
Installation note:
Apply 0.3-0.5Nm torque during bolt tightening. Use stainless steel
washers (M6 size recommended) when mounting on ferrous surfaces
to prevent galvanic corrosion. Alignment pins should face load direction.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-10F |
