Airtac CPV10M Mounting Base CPV10MJ03-12F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-12F Cylinder Mounting Bracket Details
- Model: CPV10MJ03-12F (Compatible with CPV10M series cylinders)
- Material: Anodized aluminum alloy (black oxidation finish)
- Mounting type: Through-hole double rail design
- Bore spacing: 30mm (center-to-center distance)
- Thread specification: M5×0.8 mounting screws (4 places)
- Weight: 198g ±5g (including fasteners)
- Dimensions: 76mm(L) × 42mm(W) × 14mm(H)
- Surface hardness: HV 120-140
- Temperature resistance: -20℃ to 150℃
- Corrosion protection: MIL-STD-810G salt spray tested (96hrs)
- Load capacity: Max 350N static load per rail
Precision-machined mounting base for linear actuator stabilization, featuring anti-vibration grooves and laser-etched alignment markers. The thermal-conductive design helps dissipate heat from adjacent components. Includes stainless steel M5×12 hex socket screws with Loctite pre-applied.
- Multi-axis pneumatic positioning systems
- PCB assembly robotic arms
- Automated packaging line gripper modules
- Semiconductor wafer handling equipment
- CNC machine tool auxiliary actuators
Installation note:
Apply 0.5-0.8N·m torque during screw tightening. Use shim washers
when mounting on uneven surfaces (>0.1mm flatness deviation).
Compatible with ISO 6432/DIN ISO 15552 cylinder standards.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-12F |
