Airtac CPV10M Mounting Base CPV10MJ03-7F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-7F Cylinder Mounting Bracket Specifications
- Model: CPV10MJ03-7F
- Compatible Series: CPV10M standard cylinders
- Material: Aluminum alloy (A6063-T5)
- Surface Treatment: Black anodized oxidation
- Mounting Hole Spacing: 40±0.2mm (center-to-center)
- Thread Specifications: M6×1.0 mounting threads (4 places)
- Weight: 215±5g
- Dimensions: 78mm(L) × 42mm(W) × 28mm(H)
- Operating Temperature: -20℃ to 100℃
- Max Load Capacity: 150N static / 90N dynamic
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Corrosion Protection: 96hr salt spray test compliant
Precision-machined mounting base for CPV10M series compact cylinders, featuring anti-loosening thread design with integrated vibration dampening. The diamond-knurled contact surface ensures secure mounting while maintaining thermal expansion tolerance. Compatible with both horizontal and vertical installations.
- Robotic end-effector positioning systems
- Conveyor belt sorting mechanisms
- Semiconductor wafer handling equipment
- Automated test fixture mounting
- Food processing machine linear actuators
Installation note:
Apply 0.3-0.5Nm torque during screw fastening and use spring washers.
Ensure cylinder rod alignment within ±0.5° angular tolerance. Compatible with ISO 6432 mounting standards.
- 1× CPV10MJ03-7F bracket body
- 4× M6×12 stainless steel hex socket screws
- 4× M6 flat washers
- 1× Alignment shim (0.5mm thickness)
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-7F |
