Airtac CPV10M Mounting Base CPV10MJ03-8F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-8F Mounting Base Specifications
- Model: CPV10MJ03-8F
- Compatible Series: CPV10M miniature cylinders
- Mounting Type: Side-mount (with integrated sensor slot)
- Material: Anodized aluminum alloy (black finish)
- Weight: 228g ±5g
- Dimensions: 76mm(L) × 34mm(W) × 25mm(H)
- Bolt Hole Spacing: 60mm × 25mm (M5 threaded holes)
- Sensor Slot: 18mm × 8.5mm (compatible with standard proximity sensors)
- Surface Hardness: HV400-450
- Operating Temperature: -20℃ to 80℃
- Max Lateral Load: 15N
- Protection Rating: IP54 (standard dust/water resistance)
- Corrosion Resistance: 96hr salt spray test passed
Precision-engineered mounting base optimized for CPV10M series compact cylinders, featuring dual-purpose design for mechanical fixation and sensor integration. The hardened mounting surface ensures vibration resistance in high-cycle applications (up to 1.5 million cycles). Includes pre-drilled alignment pins for quick installation.
- Robotic end-effector tooling mounts
- PCB handling pick-and-place systems
- Pharmaceutical capsule sorting machines
- Semiconductor wafer transport mechanisms
- Automated optical inspection (AOI) equipment
Installation note:
Use M5×12mm SHCS (socket head cap screws) with 4.4-5.0N·m torque.
Apply thread-locking compound for permanent installations.
Maintain 0.5mm clearance between cylinder body and base during alignment.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-8F |
