Airtac CPV10M Mounting Base CPV10MJ04-14F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-14F Cylinder Mounting Base Specifications
- Model: CPV10MJ04-14F
- Compatible Series: CPV10M standard cylinders
- Material: Aluminum alloy (6063-T5)
- Surface Treatment: Anodized (natural color)
- Mounting Hole Pattern: ISO 15552 standard (16mm spacing)
- Thread Specifications: M5×0.8 mounting screws (4 places)
- Load Capacity: Max 180N lateral force
- Weight: 218g ±5g
- Dimensions: 72mm(L) × 34mm(W) × 14mm(H)
- Operating Temperature: -20℃ to 80℃
- Vibration Resistance: ≤15Hz frequency, 1.5mm amplitude
- Corrosion Protection: Chromate conversion coating
High-precision mounting base designed for CPV10M series cylinders, featuring CNC-machined locating surfaces for vibration-damped installation. The diamond-shaped groove design allows ±2° angular adjustment during alignment. Includes stainless steel reinforcement inserts at stress points.
- Modular pneumatic assembly systems
- Multi-axis actuator mounting in robotics
- Precision fixturing for CNC machine tool changers
- Vibration-sensitive metrology equipment
- Packaging line gripper mounting stations
Installation protocol:
Use torque-controlled driver (0.8-1.2N·m) for M5 fasteners.
Apply thread-locking compound on clean, oil-free threads.
Perform concentricity check with dial indicator (max 0.05mm runout).
| Property | Property Value |
|---|---|
| sku | CPV10MJ04-14F |
