Airtac CPV10M Mounting Base CPV10MJ04-18F
$44.42
Regular price
$51.92
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ04-18F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation protocol:
Apply 2.0-2.5N·m torque during screw fastening. Use thread-locking
compound (LOCTITE 243 recommended) for high-vibration environments.
Align base within 0.1mm parallel tolerance relative to guide rails.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-18F Cylinder Mounting Base Specifications
- Model: CPV10MJ04-18F
- Compatible Series: CPV10M standard cylinders
- Material: Aluminum alloy (AL6063-T5)
- Surface Treatment: Black anodized
- Mounting Hole Spacing: 18mm (center-to-center)
- Fastener Type: M4×16 stainless steel screws (included)
- Thread Depth: 8mm ±0.2
- Weight: 0.28kg ±5%
- Dimensions: 40mm(W) × 18mm(H) × 62mm(L)
- Operating Temperature: -20℃ to 80℃
- Vibration Resistance: ≤49 m/s² (with proper fastening)
- Corrosion Protection: MIL-STD-810G salt spray tested (96hrs)
Precision-machined mounting base designed for rigid cylinder fixation in multi-axis applications. Features anti-rotation grooves and torque-resistant design, with through-hole pattern allowing optional side or bottom cable routing. Compatible with ISO 15552 mounting standards.
Typical Applications:
- Modular pneumatic assembly systems
- Palletizing robot end-effector mounts
- CNC machine tool clamping mechanisms
- Automated packaging line actuators
- Semiconductor handling equipment
Installation protocol:
Apply 2.0-2.5N·m torque during screw fastening. Use thread-locking
compound (LOCTITE 243 recommended) for high-vibration environments.
Align base within 0.1mm parallel tolerance relative to guide rails.
Pairing Guide:
Optimal performance when used with CPV10M-□-A series cylinders (10mm bore).
For angular load applications, combine with ASNU10 series pivot brackets.
