Airtac CPV10M Mounting Base CPV10MJ04-20F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-20F Cylinder Mounting Bracket Specifications
- Model: CPV10MJ04-20F
- Type: Precision-machined cylinder mounting base
- Compatible Series: CPV10M standard cylinders
- Material: 6063-T5 aluminum alloy
- Surface Treatment: Anodized (black)
- Mounting Hole Spacing: 20mm (center-to-center)
- Thread Specifications: M4×0.7 mounting screws (4 places)
- Weight: 185g ±5g
- Dimensions: 56mm(L) × 40mm(W) × 22mm(H)
- Load Capacity: Max 250N static load
- Operating Temperature: -20°C to 120°C
- Vibration Resistance: ≤50m/s² (10-150Hz)
- Corrosion Protection: MIL-STD-810F salt spray tested (96hrs)
CNC-machined mounting base featuring dual anti-rotation pins and precision alignment grooves. The hardened contact surfaces ensure stable cylinder fixation while the modular design allows tool-less installation. Includes integrated shock-absorbing pads for vibration damping in high-cycle applications.
- Linear actuator installations in pick-and-place robots
- Precision fixturing for optical component alignment systems
- Vibration-sensitive metrology equipment bases
- Multi-axis pneumatic positioning stages
- Cleanroom-compatible automation setups
Installation note:
Use 0.4-0.6Nm torque for mounting screws. Apply lithium-based grease
on sliding surfaces before assembly. Compatible with ISO 6432 mounting
patterns - verify perpendicularity within 0.05mm/m during installation.
| Property | Property Value |
|---|---|
| sku | CPV10MJ04-20F |
